High-temperature drying ovens up to 850°C

PDF Download for this category:

Technical specifications

High-temperature drying ovens KU 40/04/A – KU 540/04/A

Working temperatures up to 450°C

PDF Download for this category:

Technical specifications

Previous Next KU 40/04/A KU 70/04/A KU 140/04/A KU 270/04/A KU 540/04/A

1
2
3
4
5

Next model

Technical specifications
	Model	KU 40/04/A
	Max. temperature \| C°	450°C
	Inside dimensions \| mm	W 300 x D 400 x H 300
	Outside dimensions \| mm	W 570 x D 1020 x H 1305
	Weight \| kg	115 kg
	Volume \| l	35,0 l
	Power \| kW	3,2 kW
	Voltage \| V	230 1/N V

Next model

Technical specifications
	Model	KU 70/04/A
	Max. temperature \| C°	450°C
	Inside dimensions \| mm	W 350 x D 500 x H 400
	Outside dimensions \| mm	W 620 x D 1120 x H 1405
	Weight \| kg	130 kg
	Volume \| l	70,0 l
	Power \| kW	4,3 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 140/04/A
	Max. temperature \| C°	450°C
	Inside dimensions \| mm	W 450 x D 600 x H 500
	Outside dimensions \| mm	W 720 x D 1220 x H 1505
	Weight \| kg	205 kg
	Volume \| l	140,0 l
	Power \| kW	5,8 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 270/04/A
	Max. temperature \| C°	450°C
	Inside dimensions \| mm	W 600 x D 750 x H 600
	Outside dimensions \| mm	W 870 x D 1390 x H 1605
	Weight \| kg	370 kg
	Volume \| l	270,0 l
	Power \| kW	9,8 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 540/04/A
	Max. temperature \| C°	450°C
	Inside dimensions \| mm	W 750 x D 900 x H 800
	Outside dimensions \| mm	W 1020 x D 1540 x H 1805
	Weight \| kg	540 kg
	Volume \| l	540,0 l
	Power \| kW	13,8 kW
	Voltage \| V	400 3/N V

PDF Download for this category:

Technical specifications

High-temperature drying ovens KU 15/06/A – KU 540/06/A

Working temperatures up to 650°C

PDF Download for this category:

Technical specifications

Previous Next KU 15/06/A KU 40/06/A KU 70/06/A KU 140/06/A KU 270/06/A KU 540/06/A

1
2
3
4
5
6

Next model

Technical specifications
	Model	KU 15/06/A
	Max. temperature \| C°	650°C
	Inside dimensions \| mm	W 300 x D 350 x H 150
	Outside dimensions \| mm	W 500 x D 900 x H 440
	Weight \| kg	63 kg
	Volume \| l	15,0 l
	Power \| kW	2,6 kW
	Voltage \| V	230 1/N V

Next model

Technical specifications
	Model	KU 40/06/A
	Max. temperature \| C°	650°C
	Inside dimensions \| mm	W 300 x D 400 x H 300
	Outside dimensions \| mm	W 540 x D 1050 x H 1270
	Weight \| kg	125 kg
	Volume \| l	35,0 l
	Power \| kW	4,3 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 70/06/A
	Max. temperature \| C°	650°C
	Inside dimensions \| mm	W 350 x D 500 x H 400
	Outside dimensions \| mm	W 590 x D 1150 x H 1370
	Weight \| kg	140 kg
	Volume \| l	70,0 l
	Power \| kW	8,3 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 140/06/A
	Max. temperature \| C°	650°C
	Inside dimensions \| mm	W 450 x D 600 x H 500
	Outside dimensions \| mm	W 690 x D 1250 x H 1470
	Weight \| kg	220 kg
	Volume \| l	135,0 l
	Power \| kW	12,3 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 270/06/A
	Max. temperature \| C°	650°C
	Inside dimensions \| mm	W 600 x D 750 x H 600
	Outside dimensions \| mm	W 840 x D 1450 x H 1620
	Weight \| kg	480 kg
	Volume \| l	270,0 l
	Power \| kW	16,8 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 540/06/A
	Max. temperature \| C°	650°C
	Inside dimensions \| mm	W 750 x D 900 x H 800
	Outside dimensions \| mm	W 990 x D 1600 x H 1820
	Weight \| kg	560 kg
	Volume \| l	540,0 l
	Power \| kW	24,8 kW
	Voltage \| V	400 3/N V

PDF Download for this category:

Technical specifications

High-temperature drying ovens KU 40/07/A – KU 540/07/A

Working temperatures up to 750°C

PDF Download for this category:

Technical specifications

Previous Next KU 40/07/A KU 70/07/A KU 140/07/A KU 270/07/A KU 540/07/A

1
2
3
4
5

Next model

Technical specifications
	Model	KU 40/07/A
	Max. temperature \| C°	750°C
	Inside dimensions \| mm	W 300 x D 400 x H 300
	Outside dimensions \| mm	W 610 x D 1050 x H 1410
	Weight \| kg	140 kg
	Volume \| l	35,0 l
	Power \| kW	5,5 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 70/07/A
	Max. temperature \| C°	750°C
	Inside dimensions \| mm	W 350 x D 500 x H 400
	Outside dimensions \| mm	W 660 x D 1150 x H 1510
	Weight \| kg	170 kg
	Volume \| l	70,0 l
	Power \| kW	10,7 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 140/07/A
	Max. temperature \| C°	750°C
	Inside dimensions \| mm	W 450 x D 600 x H 500
	Outside dimensions \| mm	W 760 x D 1260 x H 1610
	Weight \| kg	290 kg
	Volume \| l	135,0 l
	Power \| kW	14,3 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 270/07/A
	Max. temperature \| C°	750°C
	Inside dimensions \| mm	W 600 x D 750 x H 600
	Outside dimensions \| mm	W 950 x D 1460 x H 1750
	Weight \| kg	590 kg
	Volume \| l	270,0 l
	Power \| kW	21,7 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 540/07/A
	Max. temperature \| C°	750°C
	Inside dimensions \| mm	W 750 x D 900 x H 800
	Outside dimensions \| mm	W 1100 x D 1610 x H 1950
	Weight \| kg	700 kg
	Volume \| l	540,0 l
	Power \| kW	28,7 kW
	Voltage \| V	400 3/N V

PDF Download for this category:

Technical specifications

High-temperature drying ovens KU 40/08/A – KU 540/08/A

Working temperatures up to 850°C

PDF Download for this category:

Technical specifications

Previous Next KU 40/08/A KU 70/08/A KU 140/08/A KU 270/08/A KU 540/08/A

1
2
3
4
5

Next model

Technical specifications
	Model	KU 40/08/A
	Max. temperature \| C°	850°C
	Inside dimensions \| mm	W 300 x D 400 x H 300
	Outside dimensions \| mm	W 850 x D 1360 x H 1470
	Weight \| kg	290 kg
	Volume \| l	35,0 l
	Power \| kW	7,1 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 70/08/A
	Max. temperature \| C°	850°C
	Inside dimensions \| mm	W 350 x D 500 x H 400
	Outside dimensions \| mm	W 900 x D 1460 x H 1570
	Weight \| kg	360 kg
	Volume \| l	70,0 l
	Power \| kW	11,0 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 140/08/A
	Max. temperature \| C°	850°C
	Inside dimensions \| mm	W 450 x D 600 x H 500
	Outside dimensions \| mm	W 1000 x D 1560 x H 1670
	Weight \| kg	580 kg
	Volume \| l	135,0 l
	Power \| kW	15,1 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 270/08/A
	Max. temperature \| C°	850°C
	Inside dimensions \| mm	W 600 x D 750 x H 600
	Outside dimensions \| mm	W 1150 x D 1710 x H 1770
	Weight \| kg	770 kg
	Volume \| l	270,0 l
	Power \| kW	21,1 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KU 540/08/A
	Max. temperature \| C°	850°C
	Inside dimensions \| mm	W 750 x D 900 x H 800
	Outside dimensions \| mm	W 1300 x D 1860 x H 1970
	Weight \| kg	920 kg
	Volume \| l	540,0 l
	Power \| kW	31,1 kW
	Voltage \| V	400 3/N V
