High temperature furnaces up to 1600°C

PDF Download for this category:

Technical specifications

High temperature furnaces KLC 05/14 – KLC 30/14

Working temperatures up to 1400°C

PDF Download for this category:

Technical specifications

Previous Next KLC 05/14 KLC 10/14 KLC 15/14 KLC 30/14

1
2
3
4

Next model

Technical specifications
	Model	KLC 05/14
	Max. temperature \| C°	1400°C
	Inside dimensions \| mm	W 150 x D 250 x H 140
	Outside dimensions \| mm	W 550 x D 580 x H 650
	Volume \| l	5,3 l
	Power \| kW	3,8 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 10/14
	Max. temperature \| C°	1400°C
	Inside dimensions \| mm	W 200 x D 250 x H 180
	Outside dimensions \| mm	W 560 x D 640 x H 720
	Volume \| l	9,0 l
	Power \| kW	5,0 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 15/14
	Max. temperature \| C°	1400°C
	Inside dimensions \| mm	W 220 x D 310 x H 220
	Outside dimensions \| mm	W 590 x D 690 x H 790
	Volume \| l	15,0 l
	Power \| kW	7,0 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 30/14
	Max. temperature \| C°	1400°C
	Inside dimensions \| mm	W 250 x D 440 x H 270
	Outside dimensions \| mm	W 660 x D 730 x H 800
	Volume \| l	29,7 l
	Power \| kW	11,5 kW
	Voltage \| V	400 3/N V

PDF Download for this category:

Technical specifications

High temperature furnaces KLC 05/15 – 30/15

Working temperatures up to 1500°C

PDF Download for this category:

Technical specifications

Previous Next KLC 05/15 KLC 10/15 KLC 15/15 KLC 30/15

1
2
3
4

Next model

Technical specifications
	Model	KLC 05/15
	Max. temperature \| C°	1500°C
	Inside dimensions \| mm	W 150 x D 250 x H 140
	Outside dimensions \| mm	W 550 x D 580 x H 650
	Volume \| l	5,3 l
	Power \| kW	4,8 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 10/15
	Max. temperature \| C°	1500°C
	Inside dimensions \| mm	W 200 x D 250 x H 180
	Outside dimensions \| mm	W 560 x D 640 x H 720
	Volume \| l	9,0 l
	Power \| kW	6,6 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 15/15
	Max. temperature \| C°	1500°C
	Inside dimensions \| mm	W 220 x D 310 x H 220
	Outside dimensions \| mm	W 590 x D 690 x H 790
	Volume \| l	15,0 l
	Power \| kW	7,0 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 30/15
	Max. temperature \| C°	1500°C
	Inside dimensions \| mm	W 250 x D 440 x H 270
	Outside dimensions \| mm	W 660 x D 730 x H 800
	Volume \| l	29,7 l
	Power \| kW	11,5 kW
	Voltage \| V	400 3/N V

PDF Download for this category:

Technical specifications

High temperature furnaces KLC 05/16 – KLC 30/16

Working temperatures up to 1600°C

PDF Download for this category:

Technical specifications

Previous Next KLC 05/16 KLC 10/16 KLC 15/16 KLC 30/16

1
2
3
4

Next model

Technical specifications
	Model	KLC 05/16
	Max. temperature \| C°	1600°C
	Inside dimensions \| mm	W 150 x D 250 x H 140
	Outside dimensions \| mm	W 550 x D 580 x H 650
	Volume \| l	5,3 l
	Power \| kW	5,2 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 10/16
	Max. temperature \| C°	1600°C
	Inside dimensions \| mm	W 200 x D 250 x H 180
	Outside dimensions \| mm	W 560 x D 640 x H 720
	Volume \| l	9,0 l
	Power \| kW	6,9 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 15/16
	Max. temperature \| C°	1600°C
	Inside dimensions \| mm	W 220 x D 310 x H 220
	Outside dimensions \| mm	W 590 x D 690 x H 790
	Volume \| l	15,0 l
	Power \| kW	7,0 kW
	Voltage \| V	400 3/N V

Next model

Technical specifications
	Model	KLC 30/16
	Max. temperature \| C°	1600°C
	Inside dimensions \| mm	W 250 x D 440 x H 270
	Outside dimensions \| mm	W 660 x D 730 x H 800
	Volume \| l	29,7 l
	Power \| kW	11,5 kW
	Voltage \| V	400 3/N V
